1969 Telecaster® NOS
1969 Telecaster® NOS
1969 Telecaster® NOS
Details
Summary
Overview
Take a journey back to 1969 with the Fender Custom Shop 1969 Telecaster® NOS. This iconic electric guitar authentically recreates the look, sound and feel of the original workhorse Telecaster model from that era.
The body is crafted from premium 2-piece select ash with an offset seam and finished in a nitrocellulose lacquer for a vintage appearance and feel. The quartersawn maple neck has a comfortable '60s Oval "C"-shaped profile and is topped with a 1-piece quartersawn maple fingerboard outfitted with 21 narrow tall frets.
For classic Tele tone, the guitar is equipped with a Custom Shop Hand-Wound '67 single-coil pickup in the neck and bridge position. The pickups are routed through a 3-position blade switch for versatile tonal options. Master volume and tone controls and knurled chrome knobs round out the electronics package.
Other premium features include 9.5" (241 mm) Radius, 21 Narrow Tall (6105) Frets, ’67 Telecaster® Wiring, 3-Ply White Pickguard, '67 Telecaster® Bridge, Vintage “F” Style Tuning Machines, Bone Nut, American Vintage '56-'58 String Tree, Deluxe Hardshell Case, Strap, Certificate of Authenticity.Accessories
Body
Body
2-Piece Select Ash with Offset Seam
Body Finish
WLS Undercoat
Body Material
2-Piece Select Ash with Offset Seam
Body Shape
Telecaster®
Body Style
Solid Body
Electronics
Bridge Pickup
Custom Shop Hand-Wound '67 Single-Coil Tele®
Controls
Master Volume, Master Tone
Neck Pickup
Custom Shop Hand-Wound '67 Single-Coil Tele®
Pickup Configuration
SS
Switching
3-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
General
Color
Target 3-Color Sunburst
Orientation
Right-Hand
Product Name
1969 Telecaster® NOS, Maple Fingerboard, Target 3-Color Sunburst
Series
Time Machine™
Hardware
Bridge
'67 Telecaster® Bridge with RSD Saddles
Control Knobs
Knurled Chrome
Hardware Finish
Nickel/Chrome
Neck Plate
4-Bolt with Custom Shop "V" Logo, Serialized
Pickguard
3-Ply White
String Trees
American Vintage '56-'58
Strings
Nickel Plated Steel (.010-.046 Gauges)
Switch Tip
Top Hat Style, Black
Tuning Machines
Fender®/Schaller® Vintage “F” Style
Measurements
Fret Size
Narrow Tall (6105)
Headstock Thickness
0.575"
Scale Length
25.5" (648 mm)
Neck
Fingerboard Material
Maple
Fingerboard Radius
9.5" (241 mm)
Headstock
Telecaster®
Neck Binding
None
Neck Butt Width
2.200"
Neck Finish
Nitrocellulose Lacquer
Neck Material
1-Piece Quartersawn Maple
Neck Shape
'60s Oval "C"
Neck Thickness
.840"
Neck Thickness 12th Fret
.900"
Number of Frets
21
Nut Material
Bone
Nut Width
1.650" (42 mm)
Position Inlays
Black Micarta Dot - 7 mm
String Nut
Bone
Truss Rod
Late '60s
